Swimming pool construction details were given in the Autocad 2D DWG drawing file. Light fitting, water outlet, stainless steel ladder, PVC grating and frame were mentioned. Section details were given. Two layer water proofing membrane 4mm torched apllied. 30mm concrete gunite and 6mm protection board were provided. The edge is finished with overflow channel which carries water through buffer tank to the filtration system. Channel is covered by grating, which is in the same level as the surrounding terrain is. Swimming-pool with overflow channel is completely sunken in the terrain. Thank you for downloading the Autocad files from our cadbull website.
