First, second and terrace floor plan details with sanitary installation of apartment building dwg file


Description

First, second and terrace floor plan details with sanitary installation of apartment building that includes a detailed view of ground, first etc with car parking area, garden area with main entry house door, drawing room and living room with family hall details kitchen and dining area, indoor staircases and laundry area and balcony, details and bedroom with toilet plan details with toilet sectional details and passage, sanitary equipment installation details, doors and ventilation details and much more of building details.




File Type: DWG File ID: 99115

Uploaded by:


Presenting the broken author avatar :D Eiz Luna
New-Zealand
