Ground floor framing plan structure details of house building dwg file


Description

Ground floor framing plan structure details of house building that includes a detailed view of wood posts with Grider pre-engineering, steel pipe column and play joints, existing floor joints, knee wall details provided. Steel pipe column with beam schedule details, dimensions details, measures and much more of framing plan details.




File Type: DWG File ID: 105311
