Electrical installation of liquid sensor details of hospital dwg file


Description

Installation of liquid sensor details of hospital that includes a detailed view of installation of magnetoestrictive probe, installation of capacitance probe, electrical installation in dispensaries, electrical details in dangerous areas, sensor switch in the tank fund, join the guide to the sensor to one foot of the asendient pipe fund and much more of electric installation details.




File Type: DWG File ID: 115757
