30x10m house building section view


30x10m house building section view is given in this file. This is a G+ 2 house building. The total height of the building is 9.3m. On the ground floor, one house is available. On the first and second floor, two houses are available. The living room, kitchen, master bedroom, guest room, kid’s room, and two common bathrooms are available. For more details download the AutoCAD drawing file from our website.

File Type: DWG File ID: 189488
