Plan and side section of water tanks.


This Architectural drawing is Plan and section of water tanks in a building. This is 5 story building. In this drawing file two types of water tank are shown one is Fire & Domestic water tank and other one is Raw & Irrigation water tank. In plan the details are shown that the what capacity of tank is used, what material is used what is the thickness and many more details are given. In side section the details of plumbing like which pipe is taking which path to supply water. For more details and information download the drawing file.

File Type: DWG File ID: 253123

Uploaded by:

Presenting the broken author avatar :D Eiz Luna
