This Architectural Drawing is AutoCAd 2d drawing of Reinforcement base plate and bolts details in AutoCAD, dwg file. Anchor bolt on column base plate plays important role to transfer loads (i.e. compression, tension and shear) from column to foundation. The main purpose of the anchor bolt is to hold down the column by transferring tensile loads to the corresponding foundation. For more details and information download trhe drawing file.
