House Drawing DWG File with Floor Plan Sections Elevations Details

This house drawing DWG file includes complete architectural details such as floor plans, front and rear elevations, side elevations, and structural layout drawings. The plan shows every room arrangement with window openings, door placements, internal walls, and service connections. Structural notes specify that 35N20 concrete must be used and not poured below 5°C. Reinforcement requirements include lap lengths for T10 (400mm), T12 (480mm), T16 (640mm), and T20 (800mm) bars, with all reinforcement securely tied using clips. Concrete cover of 50mm is required, supported by appropriate chairs and spacers. The slab buildup includes 75mm sand-cement screed over 50mm insulation, placed on DPM, above a 150mm concrete slab reinforced with A393 mesh and laid on a radon barrier and compacted hardcore.

This house drawing DWG file also provides detailed ventilation requirements for every room type. Habitable rooms require both background ventilation (wall or window vents) and rapid ventilation via windows. Kitchen and utility spaces require background ventilation, plus rapid window ventilation and a mechanical extract system. Bathrooms must include rapid ventilation and mechanical extraction. Rooms with heat-producing appliances such as stoves or fireplaces require a permanent wall vent and rapid window ventilation. The included elevation drawings, front, rear, north, and south, show roof profiles, window dimensions, and external façade proportions, while the sectional drawings illustrate slab depth, insulation layers, and structural beam positioning. This file is ideal for architects, civil engineers, and contractors requiring accurate and complete residential construction details.
