Residential House Plan AutoCAD DWG with Section and Elevation Details

This residential house AutoCAD DWG file includes a complete architectural layout featuring ground and first-floor plans, elevation, and sectional details. Each drawing is dimensioned with precision, showing the building layout, wall placements, and door-window openings. The drawing also highlights a detailed key plan for better spatial understanding. The section view clearly presents the height, beam position, and slab thickness for accurate structural reference.

The file provides a clear visualization of architectural and structural elements, making it highly valuable for architects, civil engineers, and students. The elevation showcases a modern residential façade design with proportionate window alignment and a simple front elevation concept. Additional details such as staircase design, lintel section, and foundation detailing are also included. This DWG file serves as a professional resource for learning or implementing residential building designs using AutoCAD. It is structured for practical use in both design drafting and on-site construction planning.
