Stand pipe riser and valves plumbing structure details for bathroom dwg file


Description

Stand pipe riser and valves plumbing structure details for bathroom that includes a detailed view of controller-to-valve details & wiring diagram, pipe and wire trenching, main isolation valve assembly control valve assembly with air / vacuum relief valve, drain/flush valve, dripper for palms and trees, drip line connection details, pvc to pe drip line take-off and drip irrigation for groundcovers, concrete thrust blocks, dimensions details, material details and much more of plumbing details.




File Type: DWG File ID: 74598

Uploaded by:


Eiz Luna
New-Zealand
